|LEO D - three speed FLOWAIR axial fan, EPP casing, protection level IP54|
Use below program or open in manufacturer webpage.
Its purpose is the improvement of heating efficiency in high buildings such as industrial buildings, warehouses, supermarkets, exhibition halls. It prevents accumulation of hot air in upper zones of heated areas. The axial fan forces hot air into the zone where people are present. The results are reduced heat loss and faster heating. The unit works continuously or is activated depending on the pre-set temperature (reg. units equipped with thermostat).
If the temperature in the upper levels of the area rises above the pre-set value the fan is switched on and the hot air is directed to the lower zones of the building.
The materials used guarantees proper parameters - both thermal and mechanical.
Modern design corresponding with LEO FB.
There are 4 sets of blades.
Stepless, manual regulation of the inclination angle of each blade for precise air stream separation.
Fan provides very efficient delivery of heated air.
Blades are made of plastic for weight reduction.
Special shape of blades ensures quiet operation of the unit.
Available in LEO DT.
If air temperature in upper levels rises up to the preset value the fan switches on so that the heat is brought back to lower levels.
Mounted on the lateral side of the device.
Specially designed shape of the nozzle reduces noise during air flow and increases the air volume.
